河南信杰已有多年設計制造重型錘式破碎機的經驗，重型錘式破碎機具有結構先進，性能可靠，工作平穩，能耗低的特點。重錘破可以直接將粒度為600-1200毫米的物料一次性破碎至25毫米以下。重型錘式破碎機適用于破碎搞壓強度不超過150兆帕的石灰石等各種中等硬度和脆性物料，如煤、鹽、白亞、石膏、明礬、磚、瓦、煤矸石等。

Henan Xinjie Mechanical Engineering CO,Ltd has a long history in designing and manufacturing the heavy hammer crusher,the heavy hammer crusher has features of advanced product structure,reliable performance,stable operation and low particle seze of 600-1200mm to less than 25mm.Heavy hammer crusher is suitable for crushing limestone and other kinds of medium hardness and brittle materials with the compssive strength not more than 150MPa and calcium content higher than 40%,such as coal,salt,gypsum,alum,brick,tile and coal gangue.

工作原理/WORKING PRINCIPLE

電動機帶動轉子在破碎腔內高速旋轉。物料自上部給料口給入機內，受高速運動的錘頭的打擊、沖擊、剪切、研磨作用而粉碎。在轉子下部，設有篩板、粉碎物料中小于篩孔尺寸的粒級通過篩板排出，大于篩孔尺寸的粗粒級阻留在篩板上繼續受到錘子的打擊和研磨，最后通過篩板排出。

The motor drives the rotor rotating at high speed in the crushing cavity.Materials enter into the hammer crusher through the upper feed opening,crushed by the high-speed moving hammer throuth impacting ,cutting and grinding.Beneath the rotor,there is a sieve plate,and the crushed materials with size smaller than the sieve size will be discharged by the sieve plate,while the larger one will be retained in the sieve and be impacted and grinded by the hammer continuously,finally discharged through the sieve.

結構特點/STRUCTURE FEATURES

錘式破碎機由機殼、轉子、打擊板、錘頭、支架、襯板等組成。

The hammer crusher is composed of machine case,rotor,impact plate,hammer head,frame and lining plate.

性能特點/PERFORMANCE FEATURES

1、  錘式破碎機入料粒度大，出料粒度小，變?nèi)?jí)破碎為一級破碎，徹底實現了一破頂兩破的低成本運營。因此可降低35%的成本。它是一個耗能低，投資低的設備。

The hammer crusher has large feeding size,small particle size,and can change tertiary crushing to primary crushing,

2、  錘式破碎機又稱巨石破，是在普通錘式破碎機、反擊式破碎機、立軸錘式破碎機及各種用錘頭（板錘）對石料進行打擊破料的機械原理上，經過優化設計后，制造生產出的最新一代破碎機械產品，改變了以篦條控制出料顆粒大小的方法，減少了錘頭在破碎腔內的磨損，使錘頭的壽命提高4—6倍。實現了破碎技術的重大突破，真正達到了事半功倍的效果。同時可據客戶要求，調節需要的產品粒度。

Hammer crusher,also known as boulder crusher,which is the latest generation crusher after optimized design manufactured based on the ordinary hammer crusher,impact crusher,vertical shaft hammer crusher and the mechanical principle of using a hammer head(the plate hammer) to crush materials.It can reduce the wear of the hammer in the crushing cavity,and improve the hammer life expectancy by 4-6times,achieving a big breakthrough in the crushing technology,

3、  我公司生產的錘式破碎機采用最為精良的配件，特別是耐磨件的選材上，采鉻合金的錘頭，是目前國內最為先進的技術和最為耐磨金屬件。

Hammer crusher produced by our company uses the most sophisticated accessories,especially the selection of the wear parts,adopting the chrome hammer,which is currently the most advanced technology and the most wear-resistant metal parts.

4、  它可以破碎濕料，也就是說，在破碎時可以進行加水以減少灰塵污染，保護工人健康和環境。

It can crush wet material,that is ,when crushing the materials,it can add water to reduce dust pollution,protect the health of workers and the envirjonment.
